What are the applications of bucket elevators in cement plants?
Saturday August-09 2025 16:50:16
Bucket elevators are primarily used in cement plants to lift various bulk materials such as cement raw materials, clinker, fly ash, and lime powder vertically from low to high locations. They play a key role in cement production, processing, and finished product packaging. So what are the applications of bucket elevators in cement plants?
Bucket Elevator Application in Cement Plant
In the cement production process, Cement Conveying Bucket Elevator are responsible for vertically transporting powdered or small lump materials to a specified height and are widely used in multiple links:
In the raw material pretreatment stage, bucket elevators are used to vertically lift crushed raw materials such as limestone, clay, and iron powder from the stockpile or crusher outlet to the raw material mill for grinding.
In the raw meal homogenization stage, bucket elevators convey the ground raw meal to the top of the homogenization silo to ensure uniform raw meal composition.
In the clinker burning system, bucket elevators transport preheated raw meal to the rotary kiln and lift the hot, calcined clinker from the kiln outlet to the cooler for rapid cooling.
In the cement grinding process, bucket elevators are used to lift clinker, gypsum, and mixed materials to the cement mill and transport finished cement to the cement silo for storage. During the packaging and shipping stages, bucket elevators can also lift cement from the silo to packaging machines or bulk dispensing systems.
Cement Plant Bucket Elevator Customer Case Studies
| Application Scenario | Material Lifting | Lifting Height (m) | Lifting Capacity (t/h) | Model | Remarks |
| Cement Raw Meal Preheater | Raw Meals Such as Limestone and Clay | 45 | 200 | NE200 | High-temperature resistant design, dust-proof seal |
| Clinker conveyor to cement mill | Cement clinker (lump) | 30 | 150 | TH315 | Wear-resistant bucket design, impact-resistant |
| Pulverized coal feed kiln burner | Pulverized coal (fine powder) | 25 | 50 | NSE250 | Explosion-proof, nitrogen protection |
| Finished Cement Storage | Finished Cement (Powdered) | 35 | 120 | NE150 | Low energy consumption, stable operation, and easy maintenance |
Bucket elevators are used in cement plants for raw material pre-processing, raw material handling, clinker processing, and packaging. Different equipment models are used depending on the material being conveyed. We can customize our products to meet your needs, helping you improve your cement plant's production efficiency.
