Small bucket elevator price
Wednesday August-27 2025 14:51:12
Small bucket elevator price range in from $300.00 to $3,200.00, making them the preferred choice for small-volume users. While their transporting capacity is relatively small, their specific price is affected by factors such as material, model, lifting height, and customization requirements. The following is a detailed introduction:
Small bucket elevator price chart (for reference)
| Type | Model | Lifting Height (m) | Lifting Capacity (m²/h) | Bucket Width (mm) | Price Range | Features |
| TD (Belt Type) | TD160 | 4.8 - 30 | 5.4 - 16 | 160 | $300 - $1,100 | Belt traction, suitable for powdery, granular, and small, low-abrasive materials such as grain and coal. |
| TD250 | 4.5 - 30 | 11.8 - 21 | 250 | $350 - $1,300 | Belongs to the TD series, but has a greater lifting capacity than the TD160. | |
| TH Type (Chain Type) | TH315 | 4.5 - 31 | 34 - 59 | 315 | $400-$3,472 | Chain traction, wear-resistant, capable of conveying high-temperature materials (up to 250°C). |
| TH160 | Up to 40 | 4.5-12 | 160 | $390-$1,500 | Chain traction, small model, moderate lifting capacity. | |
| D Type (Belt Type) | D160 | 4.8 - 30 | 3.1 - 8 | 160 | $360-$1,400 | Old-style belt elevator, uses centrifugal discharge and digging loading. |
| HL Type (Chain Type) | HL160 | 4.8 - 30 | 2.2 - 6 | 160 | $340-$1,320 | Chain centrifugal discharge is an earlier type of chain hoist. |
| NE Type (Plate Chain) | NE15 | Up to 40 | <16 | 150 | $400-$1,700 | Plate chain structure, large conveying capacity, suitable for abrasive materials. |
What factors influence the price of a small bucket elevator?
The price of a small bucket elevator is primarily influenced by the material, lifting height, configuration, and customization. Depending on the material being lifted and the application, the chosen small bucket elevator configuration will vary.
Material: The body and hopper of a small bucket elevator are made of carbon steel or stainless steel. Carbon steel is relatively inexpensive and commonly used in industrial applications. Stainless steel, however, is more suitable for industries like food and pharmaceuticals due to its corrosion and high-temperature resistance, and costs $100-$150 more than carbon steel.
Lifting height: The elevator can reach up to 40 meters. Higher heights require more material, a more powerful motor, and therefore a higher price. For every additional meter of lifting height, the price of a small bucket elevator increases by $50-$150.
Drive components and configuration: Traction components (such as rubber belts or metal chains), hopper design (such as plastic or stainless steel), motor power and brand, and whether a sealed design is used all affect the cost. For example, using a metal roller chain or a higher-powered motor may result in a higher price than the basic configuration.
Customization and Services: If a standard small bucket elevator doesn't meet user needs, specific customization options (such as multi-point loading and unloading, special protection, mobile or automated control), or additional installation, commissioning, and warranty services may be required. These will increase the overall cost of the equipment by approximately $100-$1,000.
The price of a small bucket elevator depends on various factors, including material, model, lifting height, configuration, and customization. When purchasing a small bucket elevator, we must first clarify our needs (such as material characteristics (e.g., particle size, moisture content, abrasiveness), required conveying capacity, and lifting height) before selecting the appropriate material and model. If you have any questions, please contact our online customer service or email us at: sale@xxdahan.com.
