Bucket Elevator for Wheat Price
Saturday September-13 2025 17:03:39
Bucket Elevator for Wheat Price is usually between $150-$13,000, and the specific price depends on the equipment type, size, material and functional features. Vertical bucket elevators, the most common type, start at $300, while high-end Z-type, non-crushing, specialized models can reach $13,000. This price difference is primarily due to differences in equipment capacity, height, material, and degree of automation.
What are the prices of different types of bucket elevators for wheat?
Bucket elevators for wheat are used in grain processing, warehousing, and agriculture for efficient vertical or inclined conveying of granular materials such as wheat and corn. Depending on the material being conveyed and the application, the model of choice varies. There are three main types: vertical (basic models cost $200-$728 USD, such as the 4-meter TD140) and Z-type (more complex, costing $500-$4000, with stainless steel models costing more).
Vertical bucket elevators for wheat range in price from $150 to $11,500 and are used to transport dry wheat, corn, grain, and other powdered, granular, and small-sized materials. They offer a maximum lifting height of 80 meters and a throughput rate ranging from 6 to 400 m³/h (e.g., the TD1000 model), meeting the needs of large grain silos and processing plants. Costs increase by $100 to $700 for each additional meter of height. Below is a price guide for common models.
| Model | Basic Configuration (4m) | Each additional meter | Maximum Delivery Capacity |
| TD140 (Minimum) | $580-$730 | +$100-$150 | 6m³/h |
| TD250 (medium size) | $1,100-$1,700 | +$230-$300 | 26m³/h |
| TD630 (large) | $2,150-$3,200 | +$430-$670 | 120m³/h |
| TD1000(maximum) | $5,800-$9,500 | +$850-$1,700 | 400m³/h |
The Z-type Bucket Elevator for Wheat, priced between $1,000 and $42,000, is commonly used for applications requiring both horizontal and vertical transport, such as from a pit to a multi-story factory building. It can handle fragile materials (such as puffed wheat and potato chips) or highly fluid pellets, with a conveying height of up to 40 meters, a horizontal section up to 30 meters, and a conveying capacity of approximately 6 m³/h (with a 2L hopper).
| Model/Parameters | Basic Model (Carbon Steel) | Mid-Range Model (Stainless Steel) | High-End Model (Customizable) |
| Price Range | $2,500-$3,600 | $3,800-$5,300 | $6,000-$13,000 |
| Conveying Capacity | 2-6 m²/h | 6-15 m²/h | 15-20 m²/h |
| Lifting Height | 5 m (old model) | 5-30 m (new model) | 20-60 m (customized) |
| Motor Power | 0.37-0.75kW | 0.75-3kW | 3-5kW (Explosion-proof Option) |
| Hopper Capacity | 1.8L-3L | 4L-8L | 8L-40L (Deep Hopper) |
| Material Options | Carbon Steel Powder Coated | 304 Stainless Steel | 316L Stainless Steel/PP Plastic |
| Additional Features | Single-Point In/Out | Multiple unloading points (3-5 ports) | PLC control + automatic cleaning |
What factors are related to Bucket Elevator for Wheat Price?
The price of a wheat bucket elevator depends on its type, material, conveying capacity, height, and technical configuration.
Conveying height: The conveying height ranges from 3 to 60 meters, with the price increasing by an average of $120 to $200 for each additional meter.
Material: Stainless steel models are 30-50% more expensive than carbon steel, with food-grade stainless steel commanding a significant premium.
Conveying capacity: The price difference between a 5-ton and 50-ton per hour unit can be 3-5 times greater.
Power: Motor power ranges from 0.4 kW to 22 kW, directly impacting cost and energy consumption.
When purchasing a bucket elevator, you should choose a model with the best cost-effectiveness. The vertical type is suitable for large conveying capacity and height. Although the Z-type machine is more expensive, it conveys materials gently without crushing them and saves 30% of layout space. You can choose based on the conveying materials and application scenarios. We also provide free material customization and product customization solutions. If you have any questions, please consult our online customer service or send an email to: sale@xxdahan.com
