Bucket Elevator for Seeds Price

Wednesday July-23 2025  17:24:04

Bucket Elevator for Seeds Price ranges from $500.00 to $6,800.00/Set. For example, the basic and simple model may start at as low as $100, while some large, high-performance and well-equipped elevators can cost up to $6,800 or even higher. The reason why the price has such a wide span is the result of many factors. ​

Bucket Elevator for Seeds Price Table (Taking TD Series as an Example)

Model	Bucket width (mm)	Conveying volume (m/h)	Bucket capacity (L)	Bucket speed (m/s)	Power (kW)	Lifting height (m)	Price (USD)	Remarks
TD160	160	5.4-16 (Q/H/ZD/SD type)	0.5-4.2	1.4-1.8	0.75-1.5	≤40	$230-$1,243	Price varies with height (about $230/meter)
TD250	250	12-35 (Q/H/ZD/SD type)	1.3-4.6	1.6	1.1-2.2	≤40	$1,100-$1,375	Steel bucket + belt structure
TD315	315	17-40 (Q/H/ZD/SD type)	2-5.8	1.6	1.5-3	≤40	$1,250-$1,750	Suitable for medium and high conveying volume
TD400	400	24-66 (Q/H/ZD/SD type)	3.1-9.4	1.8	2.2-4	≤40	$2,250-$2,500	Suitable for high conveying capacity
TD500	500	38-92 (Q/H/ZD/SD type)	4.8-15	1.8	3-5.5	≤40	$4,300-$5,000	Applicable to heavy materials
TD630	630	85-142 (H/ZD/SD type)	14-23.5	2.0	5.5-11	≤40	$6,600-$7,300	Maximum conveying capacity model

What factors affect the Bucket Elevator for Seeds Price?

Bucket Elevator for Seeds Price is related to key parameters such as material, type, configuration, lifting capacity and height. The following is a specific analysis:

Equipment type and structure

Belt type (TD type): low cost (starting from $500.00), suitable for powdery and small-grained seeds.

Ring chain type (TH/HL type): higher price ($1,500.00+), suitable for blocky or abrasive materials.

Plate chain type (NE type): high temperature resistance, high wear resistance, higher price (customized models can reach $4,189.00+).

Lifting height and output

Bucket Elevator for Seeds can reach a height of 60 meters. For every additional meter of height, the cost of steel and drive power increases, and the price increases (for example, the 4-meter basic model is $550.00, and the 10-meter model may double).

The larger the conveying capacity, the larger the hopper and motor are required. For example, the TH400 model with a conveying capacity of 47.2m³/h is about 30% more expensive than the TH300 model (28m³/h).

Materials and customization requirements

Carbon steel structure: economical and affordable, the price is usually between $400.00-$1000.00, such as the TD160 belt bucket elevator priced at $450.

Stainless steel material: strong corrosion resistance, the price is 30-50% higher than carbon steel, such as some food-grade application scenarios

Special plastic bucket (PP/ABS): suitable for ultra-low crushing rate requirements, the price is between carbon steel and stainless steel

Customization requirements

Bucket Elevator for Seeds customizes special functions, such as mobile design is 10-15% more expensive than fixed type, such as DY series mobile models:

High temperature resistant design (up to 250℃): price increase of 25-35%

Multi-point feeding/discharging system: each additional point increases the cost by 8-12%

Explosion-proof configuration: suitable for flammable dust environment, the price is 40-60% higher than conventional models

When purchasing Bucket Elevator for When choosing Bucket Elevator for Seeds, one should not only focus on the price, but should comprehensively consider factors such as material, type, lifting amount, lifting height and accessories, and choose a cost-effective Bucket Elevator for Seeds based on one's actual needs to achieve efficient and stable seed lifting operations.
