Bucket Elevator for Fly Ash Price

Thursday November-06 2025  14:48:32

Bucket Elevator for Fly Ash Price is usually between $350 and $7,500. Different types lift different types of fly ash and are used in different applications, resulting in varying price ranges. The significant price differences are mainly related to the equipment model, materials, lifting height, lifting capacity, and configuration. Different equipment parameters require different consumables, drive motors, manufacturing processes, and control systems.

The Bucket Elevator for Fly Ash Price fluctuates constantly. A small, ordinary carbon steel model with a lifting capacity of 20 tons/hour costs approximately $350-$4500, while a large model made of 304/316 stainless steel with a lifting capacity of 100 tons/hour costs $3000-$7000 or even higher. The model must be selected based on the lifting capacity and the characteristics of the fly ash. For corrosive fly ash with high moisture content, a stainless steel model is necessary. For scenarios requiring dust purification during transport, a model with a dust removal device should be selected. For high-temperature fly ash transport, a model with a cooling device should be selected.

Bucket elevator for fly ash price table (for reference only)

model	Lifting capacity (m³/h)	Bucket speed (m/s)	Spindle speed (n/min)	Hopper			Chain pitch (mm)	Weight of running parts (Kg/m)	Material size (mm)					price
				Volume (L)	Bucket width (mm)	Bucket distance (mm)
									Percentage allowed
									10	25	50	75	100
NE15	15	0.5	16.54	2.5	250	203.2	101.6	27.5	65	50	40	30	25	$350-$1000
NE30	30	0.5	16.54	7.8	300	304.8	152.4	35	90	75	58	47	40	$560-$1500
NE50	60	0.5	16.54	15.7	300	304.8	152.4	64	90	75	58	47	40	$900-1900
NE100	110	0.5	14.13	35	400	400	200	89	130	105	80	65	55	$1500-$2600
NE150	170	0.5	14.13	52.2	600	400	200	112.5	130	105	80	65	55	$1900-$3100
NE200	210	0.5	10.9	84.6	600	500	250	134	170	135	100	85	70	$2300-$3700
NE300	320	0.5	10.9	127.5	700	500	250	188	170	135	100	85	70	$2800-$4200
NE400	380	0.5	8.3	182.5	700	600	300	205	205	165	125	105	90	$3400-$5500
NE500	470	0.5	7.1	260.9	700	700	350	223	240	190	145	120	100	$4100-$5900
NE600	600	0.5	7.1	330.2	800	700	350	350	240	190	145	120	100	$4800-$6300
NE800	800	0.5	6.2	501.8	800	800	400	313	270	220	165	135	110	$5200-$7500

What impact does the manufacturer have on the Bucket Elevator for Fly Ash Price?

The Bucket Elevator for Fly Ash Price is also affected by the manufacturer. Different manufacturers produce bucket elevators for fly ash with different models, materials, and lifting capacities, resulting in price differences. However, they are all used for vertically lifting fly ash. Dahan's bucket elevators for fly ash are available in carbon steel and stainless steel, with deep and shallow hoppers available. They can lift fly ash from low locations to heights of up to 60 meters, with lifting capacities ranging from 5 to 500 cubic meters per hour. Factory direct sales start at prices as low as $350. Customization is also available depending on the properties of the fly ash (moisture, abrasiveness, corrosiveness, etc.) and the application requirements, such as mobile, high-temperature resistant, and explosion-proof models. However, customization will increase the cost.

How to choose a model based on Bucket Elevator for Fly Ash Price?

When choosing a model based on Bucket Elevator for Fly Ash Price, price is not the only factor to consider. For example, the particle size, moisture content, temperature, and abrasiveness of the fly ash to be conveyed determine the material of the equipment's casing and hopper. The conveying height and hourly conveying capacity directly determine the overall size of the equipment and the motor power. Understanding whether the selected equipment meets your conveying needs is crucial. For instance, if you need to elevate dry fly ash into a 10-meter-high silo with a conveying capacity of at least 50 tons per hour, you can choose the NE50 model, which is priced at approximately $900-$1900. Furthermore, if the standard model does not meet your needs, we can also customize products based on your materials, conveying requirements, and application site.

The Bucket Elevator for Fly Ash Price fluctuates with the market and is influenced by factors such as model, material, capacity, lifting height, and configuration. When selecting a fly ash bucket elevator, it is essential to consider the actual material conveying needs, the required lifting height, lifting capacity, and available space to choose the most cost-effective equipment. We also offer customization services, including adjustments to equipment materials, sealing structures, and bucket capacity.
